Servo Stablizer 5 KVA - 30 KVA (1/1 - 3/3)

Parameters	: 5 KVA - 30 kVA / 5 KVA - 2000 KVA
Type	: balanced 3 wire system
Cooling Method	: Air Natural cooled / Oil Cooled

Input Voltage Single Phase
Normal Range	: 150-250V
Wide Range	: 120-280V
6kVA	: 7.5/6

Input Voltage Single Phase
Normal Range	: 360-460V
Wide Range	: 300-480V
	:
Output Voltage	: 215V±1% / 415V±1%
Input Frequency	: 47-53Hz
Efficiency	: 98%
Correction Speed	(60-30) V per second
No Load Current	Less than 2% of load current

Visual indication	: Input Volts : Output Volts : Input low (each phase) : Input high (each phase)
Metering	: LED Display : Analogue Voltmeters for each phase : Analogue Amp. meters for each phase

Protection	: MCCB at Input
Cut off (Optional)	: Automatic high voltage cut off : Automatic low voltage cut off
Controls	: Auto manual switch for each phase : Increase/decrease for each phase
Metering	: Analogue LED display
Voltage selection	: Between 200 V to 230V / 400V to 430V
Insulation Type	: Class “B”
Operating temperature	: 5-50 °C
Duty cycle	Continuos

Optional Features	: Additional Metering : Surge suppression : Voltage Cut off

Relative Humidity	: Up to 90% (non condensing)
Environment	: Designed for Indoor tropical use
