Silent Generators 5 KVA - 125 KVA

TECHNICAL SPECIFICATIONS OF GENSET EQUIPMENT

DIESEL ENGINE:
TATA / LAYLAND make Diesel Engine, water cooled, Electric start, four strokes, six cylinders, 1500 RPM conforming to BS: 5514 & IS: 3046 with 10% overload for one hour in any 12 hour duration. The Engine is suitable for Gen. Set application 5 KVA / 125 KVA under normal condition and fitted with the following standard accessories.

Heavy Duty Flywheel.
Air cleaner.
Radiator.
Mechanical Governor
Lub. Oil Pump and Filter.
Instrument panel
Fuel filters and Fuel Pump.
Hoses for fuel tank.
Self Starter motor and Alternator for battery charging.
Exhaust Silencer (residential type)

ALTERNATOR:
5 KVA / 125 KVA Alternator, three phase, 1500 RPM, 0.8 power factor, four wire, Brushless, 415Volts, 50 Hz. The Alternator will be in SP-DP enclosure, self excited, self regulated, single bearing on end shield.

ACCESSORIES:

Suitable base frame of sturdy design made of M.S. Channels with necessary reinforcement to take the load of Engine & Alternator.
Fuel tank of suitable capacity with drain valve, air vents inlet and outlet connections.
1 nos. Batteries with leads and lugs.
One set of Anti Vibration pads.

STANDARD CONTROL PANEL:
Floor / Stand mounting type, totally enclosed, louvered, steel construction control panel incorporating all the standard features and with the followings.

1no.multifunction meter for showing ampere, volts and frequency.
1no. MCCB of suitable rating with short circuit protection.
1 set of Current Transformers.
Terminals for incoming and outgoing.

ACOUSTIC ENCLOSURE: The Acoustic Enclosure is designed to suppress the sound level to 75 db maximum at 1 meter distance in open free field environment as per ISO 8528 part 10.
